SVEN SV645

UPS battery 6V 4,5Ah

Catalog Electrical Equipment Batteries SVEN SV645

AN: SV-0222064

SVEN SV645

UPS battery 6V 4,5Ah

Short product description:

Lead-acid AGM type storage battery
Leak-proof design
Doesn't require maintenance and service
Safe system of internal pressure control valves

All features

Similar products

SVEN SV1250

SVEN SV1270

SVEN SV1272

SVEN SV1290

SVEN SV12120

SVEN SV12170

SVEN SV121000

FEATURES
SPECIFICATIONS
DESCRIPTION
UNBOXING VIDEO
SUPPORT

Lead-acid battery of AGM type
Leak-proof design
Maintenance-free: doesn't require maintenance and can operate in any position
Design of interelectrode separators made of glass fiber increases service life
Does not liberate gas during operation
Valve system protecting the battery against increased pressure
Highly effective lead-calcium electrode grids increasing capacity
Lowered self-discharge current

Battery type	Lead-acid AGM type storage battery
Rated voltage, V	6
Maximum discharge current, A	67
Capacity (20 hours discharge), А • h	4.5
Maximum charging current, A	1.35
Internal resistance, MOhm	21
Self-discharge (at 25 °C of initial capacity) during the year	up to 36 %
Rated operating temperature, °C	25
Operating temperature range, °C	-20 up to +50
Terminal type	F1
Length, mm	70
Width, mm	48
Hight, mm	101
Total hight, mm	106
Weight, kg	0.7
Color	black
Life time	5 years

Other items

SVEN VR-A1000

Relay automatic voltage regulator, 600 W, socket

SVEN KB-C2100W

Wireless keyboard

SVEN MK-100

Wired dynamic microphone

SVEN KB-E5700H

Wired keyboard with 2 USB ports

SVEN SF-05LU

5 sockets surge protector, 2 USB ports, 2300 W

SVEN Pro 1000 (USB)

Line interactive UPS, 720W, 3 sockets

SVEN SPS-509

USB powered speakers with cabled volume control

SVEN RX-G720

Gaming mouse

SVEN Pro 650 (LCD, USB)

Line interactive UPS with LCD, 390W, 2 sockets, USB

SVEN MP-02 Lake

Fabric mouse pad with rubber backing

SVEN SV1250

UPS battery 12V 5Ah

SVEN 325

Speaker system with illuminated volume control

As of today the lead-acid maintenance-free batteries of AGM type are the most widespread type of batteries for the reserve power supply. The main fields of application are UPS; light, alarm and security systems; direct-current power supply; automatic control system.

Batteries of SVEN SV series are notable for the following specifications: low self-discharge current, wide operation temperature range, high coefficient of efficiency and quality of manufacture.
