SVEN Power Smart 3000

Catalog Electrical Equipment Uninterruptible Power Supplies SVEN Power Smart 3000

SVEN Power Smart 3000

Short product description:

Digital microprocessor control
High efficiency
Wide range of auto voltage regulation (АVR)
Sinusoidal output voltage both in on-line and off-line mode ...

All features

Similar products

SVEN Pro 400

SVEN Pro 600

SVEN Pro 650 (LCD, USB)

SVEN Pro 800

SVEN Pro 1000 (USB)

SVEN Pro 1500 (LCD, USB)

SVEN UP-L800

SVEN UP-L1000E

SVEN RT-500

SVEN RT-1000

FEATURES
SPECIFICATIONS
DESCRIPTION
UNBOXING VIDEO
SUPPORT

Digital microprocessor control
High efficiency
Wide range of auto voltage regulation (АVR)
Sinusoidal output voltage both in on-line and off-line mode
Built-in surge protector
Highly informative display indicating variables and basic operation modes
Option of off-line operation mode sound signal switch-off by pressing a button on the front panel
Sound alarm at critical discharge level of storage batteries (without switch-off option)
USB and RS-232 communication port
Nominal output voltage set by the user
Impulse suppression connector for network equipment (modem, fax) protection
Cold Start function at DC power supply
Battery charge level indication in on-line and off-line mode
Automatic recharge and deep battery discharge prevention system (ABM system)
Automatic electricity delivery mode at power supply renewal
Passive ventilation allows noiseless operation
Short-circuit and overload protection
Convenient and simple battery replacement

Maximum load, VA/W	3000/1800
Input voltage level, V	220/230/240 ± 25 % (determined by the user)
Output voltage level, V	220/230/240 +12 % … -14 % (on-line), 220/230/240 +3 % … -10 % (off-line)
Output voltage waveform	sine wave (on-line), sine wave (off-line)
Frequency, Hz	50/60 (determined by the user)
Communication port	USB, RS-232
Input terminals	IEC 320 (plug)
Output sockets	IEC 320 from the inverter (6 pieces) + terminals for screw connection
Protection	from high input current, short circuit, overload, lightning stroke, voltage surges, falls, brownouts, blackouts. Modem / telephone circuit protection
Alarm signals	30 dB beeps at a distance of 1 meter
Accumulator type	maintenance-free sealed lead-acid batteries (consumables)
Accumulators capacity	12 V х 9 А h (4 pieces)
Typical switching time, ms	4
Batteries operation time, min	2.7/7.9 (full load/half load)
Indicators	of operating modes, level of battery load and charge, AVR operating modes, correct networking and grounding
Processor	RISC-microprocessor based
Controlled variable	current input and output voltage, frequency, output power, battery condition and charge level, temperature inside the case
Environment operation conditions	<5000 m above sea level , 0-50 °C, moisture 0 - 90% without condensation
Supported interfaces	intelligent software support of Win Mе/NT/2000/XP/Vista
Certificates	UL. cUL, FCC, [CE,TUV] РосТест
Floating time	4 hours (up to >85 %), 10 hours max (up to >90 %)
Dimensions (W × H × D), mm	472 x 173 x 247
Weight, kg	26
Life time	5 years
